Projecta Workshop 2100 charger Auto/Manual Battery Charger (6/12/24V~12A)
HDBC35 - Projecta Battery Charger 6v/12v/24v 12 Amp
With today's reliance on efficient and high output battery power for the vehicles on road there has been an inherent advance in technology of these units not to mention an increased cost through the use of more complex materials. Keeping your battery running in peak condition and maximising its life span is where using the right charger for your purpose becomes necessary.
The HDBC20 is a professional-grade workshop battery charger designed for a wide range of applications, especially in mechanical workshops and for auto electricians.
Its robust design and versatile features make it a reliable tool for various battery charging applications.
Features:
Multi-Voltage Operation: The charger can be adjusted to charge 6, 12, or 24-volt batteries.
Flexible Charging Modes: It offers both automatic and manual charging options, allowing the operator full control over the charging process.
Engine Start Function: Includes an engine start function, which is useful for workshop environments.
Built-in Timer: A 0-14 hour timer automatically switches off the charger after the set time to prevent overcharging.
High Performance: Perfectly suited for a workshop environment due to its power and ability to handle multiple battery types.
LED Display: Displays Volt and Amp readings for accurate charge status
Innovative transformer core: Delivers a more compact and portable charger without compromising on power.
Override Button: Capable of recharging completely flat batteries from Zero Volts
Specifications:
Charger Type: 2-stage battery charger
Type: Manual and Automatic
Output: 21 Amp
Input: 240VAC 50HZ
Output Voltage: (Nominal) 6VDC/12VDC/24VDC
Output Current (Continuous): 21A @ 6VDC, 21A @ 12.5VDC , 13.5A @ 26VDC
Charge Control:
Cut out: 6V 7.1V, 12V 14.2V, 24V 28.4V
Cut in: 6V 6.7V, 12V 13.4V, 4V 26.8V
Output lead specifications: 6mm2 cable, 183cm
Dimensions (mm) 301L x 264W x 161H
Weight: 13.4kg
Warranty: One Year
| Nominal voltage | 6VDC/12VDC/24VDC |
|---|---|
| Charging current | 21A @ 6VDC, 21A @ 12.5VDC , 13.5A @ 26VDC |
| Type of charger | 2-stage battery charger |
| Dimensions (mm) | 301L x 264W x 161H |
| Weight | 13.4kg |
| Warranty | 12 months |
